Timken 43131 - 43319D bearing
All our Timken 43131 - 43319D bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken 43131 - 43319D
  |
| Bearing Weight | 2.7264 lb
1.2367 Kg
|
| D - Cup Outer Diameter | 3.1875 in
80.963 mm
|
| d - Cone Bore | 1.3125 in
33.338 mm
|
| B - Cone Width | 0.9478 in
24.074 mm
|
| C - Double Cup Width | 1.5625 in
39.688 mm
|
| T - Bearing Width across Cones | 2.1875 in
55.563 mm
|
| Z - Number of Rollers Per Row | 13
|
| Ka - Locking Pin Diameter | N/A
|
| Kb - Locking Pin Depth | N/A
|
| R - Cone Backface "To Clear" Radius1 | 0.140 in
3.600 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.06 in
1.5 mm
|
| db - Cone Backface Backing Diameter | 2.01 in
51.10 mm
|
| Da - Cup Frontface Backing Diameter | 2.94 in
73.91 mm
|
| Aa - Cage-Cone Backface Clearance | 0.13 in
3.30 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 5360 lbf
23900 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 36000 lbf
160000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 9340 lbf
41500 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 6130 lbf
27300 N
|
| Y1 - ISO Factor3 | 0.41
0.60
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 16.8
|
| G2 - Heat Generation Factor (Rib-Roller End) | 7.57
|
| Cg - Geometry Factor6 | 0.0774
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 43131 - 43319D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 43131 - 43319D Bearings, welcome to your calling.
FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF
please contact EMAIL :sales@tanchin.hk for any inquiry
dimensions Timken Tapered Roller 43131 - 43319D Bearings_TS SPEC -Tancbearing
