Timken EE291175 - 291751CD bearing
All our Timken EE291175 - 291751CD bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken EE291175 - 291751CD
  |
| Cone Part Number | EE291175
|
| Bearing Weight | 138.3756 lb
62.7661 Kg
|
| D - Cup Outer Diameter | 17.5000 in
444.500 mm
|
| d - Cone Bore | 11.7500 in
298.450 mm
|
| B - Cone Width | 2.4375 in
61.913 mm
|
| C - Double Cup Width | 3.8750 in
98.425 mm
|
| T - Bearing Width across Cones | 5.7499 in
146.047 mm
|
| Z - Number of Rollers Per Row | 29
|
| Ka - Locking Pin Diameter | 1.25 in
31.8 mm
|
| Kb - Locking Pin Depth | 0.5 in
12.7 mm
|
| R - Cone Backface "To Clear" Radius1 | 0.310 in
7.900 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.06 in
1.5 mm
|
| db - Cone Backface Backing Diameter | 13.07 in
332.00 mm
|
| Da - Cup Frontface Backing Diameter | 16.34 in
415.04 mm
|
| Aa - Cage-Cone Backface Clearance | 0.45 in
11.40 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 51700 lbf
230000 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 347000 lbf
1540000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 90000 lbf
400000 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 33400 lbf
149000 N
|
| Y1 - ISO Factor3 | 0.84
1.25
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 1580
|
| G2 - Heat Generation Factor (Rib-Roller End) | 245
|
| Cg - Geometry Factor6 | 0.156
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken EE291175 - 291751CD Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken EE291175 - 291751CD Bearings, welcome to your calling.
FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF
please contact EMAIL :sales@tanchin.hk for any inquiry
