Timken EE420751 - 421451CD bearing

All our Timken EE420751 - 421451CD bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken EE420751 - 421451CD

Series 420000
Cone Part Number EE420751
Cup Part Number 421451CD
Design Units Imperial
Bearing Weight 181.2976 lb
82.2351 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 14.5000 in
368.300 mm
d - Cone Bore 7.5000 in
190.500 mm
B - Cone Width 3.4999 in
88.897 mm
C - Double Cup Width 5.3750 in
136.525 mm
T - Bearing Width across Cones 7.6249 in
193.672 mm
Z - Number of Rollers Per Row 23
Ka - Locking Pin Diameter 1.375 in
34.9 mm
Kb - Locking Pin Depth 0.5 in
12.7 mm
R - Cone Backface "To Clear" Radius1 0.250 in
6.400 mm
r - Cup Frontface "To Clear" Radius2 0.06 in
1.5 mm
db - Cone Backface Backing Diameter 8.94 in
227.10 mm
Da - Cup Frontface Backing Diameter 13.21 in
335.53 mm
Aa - Cage-Cone Backface Clearance 0.75 in
19.10 mm
C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 68100 lbf
303000 N
C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 457000 lbf
2030000 N
C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 118000 lbf
527000 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)4 46800 lbf
208000 N
K - Factor1 1.45
e - ISO Factor2 0.86
Y1 - ISO Factor3 0.78
1.16
Y2 - ISO Factor4 1.16
G1 - Heat Generation Factor (Roller-Raceway)5 1150
G2 - Heat Generation Factor (Rib-Roller End) 128
Cg - Geometry Factor6 0.145


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken EE420751 - 421451CD Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken EE420751 - 421451CD Bearings, welcome to your calling.
