Timken EE420801 - 421451CD bearing

All our Timken EE420801 - 421451CD bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken EE420801 - 421451CD

Series 420000
Cone Part Number EE420801
Cup Part Number 421451CD
Design Units Imperial
Bearing Weight 169.5636 lb
76.9127 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 14.5000 in
368.300 mm
d - Cone Bore 8.0000 in
203.200 mm
B - Cone Width 3.4999 in
88.897 mm
C - Double Cup Width 5.3750 in
136.525 mm
T - Bearing Width across Cones 7.6249 in
193.672 mm
Z - Number of Rollers Per Row 23
Ka - Locking Pin Diameter 1.375 in
34.9 mm
Kb - Locking Pin Depth 0.5 in
12.7 mm
R - Cone Backface "To Clear" Radius1 0.130 in
3.300 mm
r - Cup Frontface "To Clear" Radius2 0.06 in
1.5 mm
db - Cone Backface Backing Diameter 9.06 in
230.10 mm
Da - Cup Frontface Backing Diameter 13.21 in
335.53 mm
Aa - Cage-Cone Backface Clearance 0.75 in
19.10 mm
C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 68100 lbf
303000 N
C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 457000 lbf
2030000 N
C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 118000 lbf
527000 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)4 46800 lbf
208000 N
K - Factor1 1.45
e - ISO Factor2 0.86
Y1 - ISO Factor3 0.78
1.16
Y2 - ISO Factor4 1.16
G1 - Heat Generation Factor (Roller-Raceway)5 1150
G2 - Heat Generation Factor (Rib-Roller End) 128
Cg - Geometry Factor6 0.145


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken EE420801 - 421451CD Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken EE420801 - 421451CD Bearings, welcome to your calling.
bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF



please contact EMAIL :sales@tanchin.hk for any inquiry



SPEC price Timken Tapered Roller EE420801 - 421451CD Bearings_TS -Tancbearing

  • bearing EE420801 - 421451CD bearing
  • bearing EE420801 - 421451CD bearing
  • bearing EE420801 - 421451CD bearing
  • bearing EE420801 - 421451CD bearing
  • bearing EE420801 - 421451CD bearing
  • bearing EE420801 - 421451CD bearing
  • bearing EE420801 - 421451CD bearing
  • bearing EE420801 - 421451CD bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

 Model:
EE420801/421417
Category:
TaperedRollerBearings
C0r:
1820000N
B:
88.897mm
Brand:
TIMKENBearing
d:
203.200mm
Cr:
1080000N
D:
360.000mm
m:
35.59kg
C0r:
1820000N
D:
368.300mm
d:
203.200mm
m:
37.95kg
B:
88.897mm
Brand:
TIMKENBearing
Cr:
1080000N
Model:
EE420801/421450
Category:
TaperedRollerBearings
Brand:
TIMKENBearing
B:
88.897mm
C0r:
1820000N
d:
203.200mm
Category:
TaperedRollerBearings
D:
365.049mm
m:
37.02kg
Model:
EE420801/421437
Cr:
1080000N
m:
78.57kg
Brand:
TIMKENBearing
D:
368.300mm
Category:
TaperedRollerBearings
d:
203.200mm
Cr:
280000N
C0r:
193000N
Model:
EE420801/421451CD/X3S-420801
B:
136.525mm
Recommended models
385A - 384ED   399AS - 394DC   43117 - 43319D   EE435102 - 435165DC   395-S - 394D   37431 - 37626DC   37431 - 37626D   395A - 394D   3778 - 3729D   392 - 394D   EE420751 - 421451CD   442-S - 432D   387A - 384D   395 - 394D   444 - 432D   42362 - 42587DC   EE435102 - 435165D   456 - 452D   385X - 384D   436 - 432D   461 - 452D   466-S - 452D   385X - 384ED   387AS - 384ED   43131 - 43319D   EE420801 - 421451CD   47490 - 47420D   3784 - 3729D   3775 - 3729DC   42381 - 42587DC
