Timken EE430888 - 431576CD bearing
All our Timken EE430888 - 431576CD bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken EE430888 - 431576CD
  |
| Cone Part Number | EE430888
|
| Bearing Weight | 197.2800 lb
89.4846 Kg
|
| D - Cup Outer Diameter | 15.7500 in
400.050 mm
|
| d - Cone Bore | 8.8750 in
225.425 mm
|
| B - Cone Width | 3.4375 in
87.313 mm
|
| C - Double Cup Width | 5.3750 in
136.525 mm
|
| T - Bearing Width across Cones | 7.3749 in
187.322 mm
|
| Z - Number of Rollers Per Row | 24
|
| Ka - Locking Pin Diameter | 1.5 in
38.1 mm
|
| Kb - Locking Pin Depth | 0.5 in
12.7 mm
|
| R - Cone Backface "To Clear" Radius1 | 0.060 in
1.500 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.06 in
1.5 mm
|
| db - Cone Backface Backing Diameter | 9.88 in
251.00 mm
|
| Da - Cup Frontface Backing Diameter | 14.49 in
364.24 mm
|
| Aa - Cage-Cone Backface Clearance | 0.58 in
14.70 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 65500 lbf
291000 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 440000 lbf
1960000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 114000 lbf
507000 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 49300 lbf
219000 N
|
| Y1 - ISO Factor3 | 0.70
1.04
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 1350
|
| G2 - Heat Generation Factor (Rib-Roller End) | 143
|
| Cg - Geometry Factor6 | 0.157
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken EE430888 - 431576CD Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken EE430888 - 431576CD Bearings, welcome to your calling.
