Timken EE430902 - 431576CD bearing

All our Timken EE430902 - 431576CD bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken EE430902 - 431576CD

Series 430000
Cone Part Number EE430902
Cup Part Number 431576CD
Design Units Imperial
Bearing Weight 188.7580 lb
85.6191 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 15.7500 in
400.050 mm
d - Cone Bore 9.0000 in
228.600 mm
B - Cone Width 3.4375 in
87.313 mm
C - Double Cup Width 5.3750 in
136.525 mm
T - Bearing Width across Cones 7.3749 in
187.322 mm
Z - Number of Rollers Per Row 24
Ka - Locking Pin Diameter 1.5 in
38.1 mm
Kb - Locking Pin Depth 0.5 in
12.7 mm
R - Cone Backface "To Clear" Radius1 0.780 in
19.800 mm
r - Cup Frontface "To Clear" Radius2 0.06 in
1.5 mm
db - Cone Backface Backing Diameter 11.42 in
290.10 mm
Da - Cup Frontface Backing Diameter 14.49 in
364.24 mm
Aa - Cage-Cone Backface Clearance 0.58 in
14.70 mm
C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 65500 lbf
291000 N
C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 440000 lbf
1960000 N
C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 114000 lbf
507000 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)4 49300 lbf
219000 N
K - Factor1 1.33
e - ISO Factor2 0.96
Y1 - ISO Factor3 0.70
1.04
Y2 - ISO Factor4 1.04
G1 - Heat Generation Factor (Roller-Raceway)5 1350
G2 - Heat Generation Factor (Rib-Roller End) 143
Cg - Geometry Factor6 0.157


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken EE430902 - 431576CD Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken EE430902 - 431576CD Bearings, welcome to your calling.
