Timken EE435102 - 435165D bearing
All our Timken EE435102 - 435165D bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken EE435102 - 435165D
  |
| Cone Part Number | EE435102
|
| Bearing Weight | 193.2328 lb
87.6489 Kg
|
| D - Cup Outer Diameter | 16.5000 in
419.100 mm
|
| d - Cone Bore | 10.2500 in
260.350 mm
|
| B - Cone Width | 3.3125 in
84.138 mm
|
| C - Double Cup Width | 5.3750 in
136.525 mm
|
| T - Bearing Width across Cones | 7.2499 in
184.147 mm
|
| Z - Number of Rollers Per Row | 26
|
| Ka - Locking Pin Diameter | N/A
|
| Kb - Locking Pin Depth | N/A
|
| R - Cone Backface "To Clear" Radius1 | 0.250 in
6.400 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.06 in
1.5 mm
|
| db - Cone Backface Backing Diameter | 11.61 in
294.90 mm
|
| Da - Cup Frontface Backing Diameter | 15.59 in
395.22 mm
|
| Aa - Cage-Cone Backface Clearance | 0.55 in
14.00 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 65500 lbf
291000 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 440000 lbf
1960000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 114000 lbf
507000 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 67800 lbf
302000 N
|
| Y1 - ISO Factor3 | 0.47
0.70
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 1480
|
| G2 - Heat Generation Factor (Rib-Roller End) | 123
|
| Cg - Geometry Factor6 | 0.179
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken EE435102 - 435165D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken EE435102 - 435165D Bearings, welcome to your calling.
