Specifications for this item
Bearing Type Ball Bearing
Bore Diameter 17 millimeters
Brand Name FAG Bearings
Compatible Lubricant Type Grease
Dynamic Load Capacity 1070 pounds

Item Diameter 40 millimeters
Item Weight 2.40 ounces
Material Alloy Steel
Maximum Rotational Speed 20000 rpm
Measurement System Metric
Number of Items 1
Part Number 6203-2RSR-L038-C3
Specification Met Din 623-1 , Din 620-4 , Iso 281 , Din 625-1 , Iso 286 , Iso 683-17 , Din Iso 281 , En 10139 , Sae J403
Static Load Capacity 2150 pounds

Width 12 millimeters


FAG 6203-2RSR-C3 Deep Groove Ball Bearing, Single Row, Double Sealed, Steel Cage, C3 Clearance, Metric, 17mm ID, 40mm OD, 12mm Width, 12000rpm Maximum Rotational Speed, 1070lbf Static Load Capacity, 2150lbf Dynamic Load Capacity
